Focus on grooving machine manufacturing and service for 28 years.

MDF Board Grooving Machine can be customized to your needs 1

MDF Board Grooving Machine can be customized to your needs 2

MDF Board Grooving Machine can be customized to your needs 3

MDF Board Grooving Machine can be customized to your needs

It can able to cut the crosswise and lengthwise v groove (u groove ,L groove) on the board or MDF by once feeding. The dual direction grooving machine is exclusively patented by Saili company . It can able to cut the crosswise and lengthwise v shape groove (u groove , L groove ) on the grey board or MDF by one pass, for bending or folding purpose of gift boxes, hardcovers or other packages.

Function: 1 Auto feeding →crosswise grooving →conveying →lengthwise grooving→Auto collector

Can do U , V and L shape groove

Any Saili grooving machine can be customized to your needs .

Inquiry

Write a Review

Main advantages

● The machine is mainly include 4 parts : first grooving part ,collecting & conveying part , second grooving part ,dedicated conveyor belt for delivery final cardboard .

● Use longer aligning device and collecting & conveying part to ensure that the cardboard go straight into each grooving parts,then improve the grooving accuracy ,to avoid the high and low corners of box by poor grooving accuracy .

● Improve product quality, improve production efficiency, saves labor .

Product details

4 (17)

5 (16)

6 (6)

Technical Parameter

Board Width	100-600mm	Board Length	100-600mm
Board thickness	1.5-4.0mm ,can be work with 4mm MDF	Normal grooving accuracy	±0.15mm
The highest grooving accuracy	±0.1mm	Grooving angle	80-140degree adjustable
Grooving tool on the first step	8sets	Grooving tool on the second step	4sets
Big Drum number	2	Machine power	6KW
Normal speed	80-100PCS/Min (300*300MM)	Main dimension	263539001350mm

Technical Parameter

Material size of 1st step	Length 195-560mm ,width 195-560mm	Material size of 2nd step	Length 195-560mm, width 195-560mm
Grooving knives of 1st step	6 sets	Grooving knives of 2nd step	6 sets
Best accuracy	±0.05mm	Normally accuracy	±0.1mm
Material thickness	200-350GSM	Grooving angle	80-140 degree adjustable , (90º=80º-110º ,120º=110º-140º)
Angle adjustable type	Each knife head can be adjustable independently	Speed	80-100PCS/Min
Quantity of girder (crossbeam )	2 sets	Quantity of knife row	3 rows ( 1 rows of knives on the 1st girder ,2 rows of knives on the 2nd girder )
The way of feeding paper	Feida air feeding system	Platform type of adding paper	Upper and lower platform ( save the time of paper putting )
Adjustable knife left position or right	Servo automatic positioning	Grooving depth	Manual adjustment is required for the first time . When you change the product and the knife, as long as the grooving angle is unchanged, there is no need to adjust the depth by second time .
Rolling belt adjustment	Remove the belt quickly by hand wheel	Waste cleaning system	Automatic waste cleaning system with air system+ 2 dedicated conveyor belts
Weight	5200KGS	Power	13.5KW
Machine dimension	320029501570mm	Edge correction principle of 1st step	Belt correction + steel ball correction
Edge correction principle of 2st step	Belt correction + steel ball correction	90º turn around system (direction change)	Drum flipping
